螺纹六角形隔离柱 HTSN-2/HNSM-2/HTSN-3
尼龙6.6 黑色
| 料号 | 类别 | 螺纹 | L (mm) | H (mm) | P2 (mm) | B (mm) | 包装数量 |
| HNSM2.5-5-5-2 | 1 | M2.5 | 5 | 5 | 3 | - | 500 |
| HNSM2.5-8-5-2 | 1 | M2.5 | 8 | 5 | 5 | - | 500 |
| HNSM2.5-10-5-2 | 1 | M2.5 | 10 | 5 | 8 | - | 500 |
| HNSM2.5-12-5-2 | 1 | M2.5 | 12 | 5 | 9 | - | 500 |
| HNSM2.5-15-5-2 | 1 | M2.5 | 15 | 5 | 10 | - | 500 |
| HNSM2.5-18-5-2 | 1 | M2.5 | 18 | 5 | 10 | - | 500 |
| HNSM2.5-20-5-2 | 1 | M2.5 | 20 | 5 | 10 | - | 500 |
| HNSM2.5-25-5-2 | 1 | M2.5 | 25 | 5 | 10 | - | 500 |
| HNSM3-10-5.5-2 | 1 | M3 | 10 | 5.5 | 8 | - | 500 |
| HNSM3-12-5.5-2 | 1 | M3 | 12 | 5.5 | 9 | - | 500 |
| HNSM3-15-5.5-2 | 1 | M3 | 15 | 5.5 | 10 | - | 500 |
| HNSM3-18-5.5-2 | 1 | M3 | 18 | 5.5 | 10 | - | 500 |
| HNSM3-20-5.5-2 | 1 | M3 | 20 | 5.5 | 10 | - | 500 |
| HNSM3-25-5.5-2 | 1 | M3 | 25 | 5.5 | 10 | - | 500 |
| HNSM3-30-5.5-2 | 1 | M3 | 30 | 5.5 | 10 | - | 500 |
| HNSM3-35-5.5-2 | 1 | M3 | 35 | 5.5 | 10 | - | 500 |
| HTSN-M3-5-5.5-2 | 1 | M3 | 5 | 5.5 | 3 | - | 500 |
| HTSN-M3-8-5.5-2 | 1 | M3 | 8 | 5.5 | 5 | - | 500 |
| HTSN-M3-5-6-2 | 1 | M3 | 5 | 6 | 3 | - | 500 |
| HTSN-M3-8-6-2 | 1 | M3 | 8 | 6 | 5 | - | 500 |
| HTSN-M3-10-6-2 | 1 | M3 | 10 | 6 | 8 | - | 500 |
| HTSN-M3-12-6-2 | 1 | M3 | 12 | 6 | 9 | - | 500 |
| HTSN-M3-15-6-2 | 1 | M3 | 15 | 6 | 10 | - | 500 |
| HTSN-M3-18-6-2 | 1 | M3 | 18 | 6 | 10 | - | 500 |
| HTSN-M3-20-6-2 | 1 | M3 | 20 | 6 | 10 | - | 500 |
| HTSN-M3-25-6-2 | 1 | M3 | 25 | 6 | 10 | - | 500 |
| HTSN-M3-30-6-2 | 1 | M3 | 30 | 6 | 10 | - | 500 |
| HTSN-M3-35-6-2 | 1 | M3 | 35 | 6 | 10 | - | 500 |
| HTSN-M3-5-8-2 | 1 | M3 | 5 | 8 | 3 | - | 500 |
| HTSN-M3-8-8-2 | 1 | M3 | 8 | 8 | 5 | - | 500 |
| HTSN-M3-10-8-2 | 1 | M3 | 10 | 8 | 8 | - | 500 |
| HTSN-M3-12-8-2 | 1 | M3 | 12 | 8 | 9 | - | 500 |
| HTSN-M3-15-8-2 | 1 | M3 | 15 | 8 | 10 | - | 500 |
| HTSN-M3-18-8-2 | 1 | M3 | 18 | 8 | 10 | - | 500 |
| HTSN-M3-20-8-2 | 1 | M3 | 20 | 8 | 10 | - | 500 |
| HTSN-M3-25-8-2 | 1 | M3 | 25 | 8 | 10 | - | 500 |
| HTSN-M3-30-8-2 | 1 | M3 | 30 | 8 | 10 | - | 500 |
| HTSN-M3-35-8-2 | 1 | M3 | 35 | 8 | 10 | - | 500 |
| HTSN-M4-5-8-2 | 1 | M4 | 5 | 8 | 3 | - | 500 |
| HTSN-M4-8-8-2 | 1 | M4 | 8 | 8 | 5 | - | 500 |
| HTSN-M4-10-8-2 | 1 | M4 | 10 | 8 | 8 | - | 500 |
| HTSN-M4-12-8-2 | 1 | M4 | 12 | 8 | 9 | - | 500 |
| HTSN-M4-15-8-2 | 1 | M4 | 15 | 8 | 10 | - | 500 |
| HTSN-M4-18-8-2 | 1 | M4 | 18 | 8 | 10 | - | 500 |
| HTSN-M4-20-8-2 | 1 | M4 | 20 | 8 | 10 | - | 500 |
| HTSN-M4-25-8-2 | 1 | M4 | 25 | 8 | 10 | - | 500 |
| HTSN-M4-30-8-2 | 1 | M4 | 30 | 8 | 10 | - | 500 |
| HTSN-M4-35-8-2 | 1 | M4 | 35 | 8 | 10 | - | 500 |
| HTSN-M4-40-8-2 | 1 | M4 | 40 | 8 | 10 | - | 500 |
| HTSN-M5-10-10-2 | 1 | M5 | 10 | 10 | 8 | - | 500 |
| HTSN-M5-12-10-2 | 1 | M5 | 12 | 10 | 9 | - | 500 |
| HTSN-M5-15-10-2 | 1 | M5 | 15 | 10 | 10 | - | 500 |
| HTSN-M5-18-10-2 | 1 | M5 | 18 | 10 | 10 | - | 500 |
| HTSN-M5-20-10-2 | 1 | M5 | 20 | 10 | 10 | - | 500 |
| HTSN-M5-25-10-2 | 1 | M5 | 25 | 10 | 10 | - | 500 |
| HTSN-M5-30-10-2 | 1 | M5 | 30 | 10 | 10 | - | 500 |
| HTSN-M5-35-10-2 | 1 | M5 | 35 | 10 | 10 | - | 500 |
| HTSN-M5-40-10-2 | 1 | M5 | 40 | 10 | 10 | - | 500 |
| HTSN-M2.5-5-3 | 2 | M2.5 | 5 | 5 | - | 6 | 500 |
| HTSN-M2.5-8-3 | 2 | M2.5 | 8 | 5 | - | 6 | 500 |
| HTSN-M2.5-10-3 | 2 | M2.5 | 10 | 5 | - | 6 | 500 |
| HTSN-M2.5-12-3 | 2 | M2.5 | 12 | 5 | - | 6 | 500 |
| HTSN-M2.5-15-3 | 2 | M2.5 | 15 | 5 | - | 6 | 500 |
| HTSN-M2.5-20-3 | 2 | M2.5 | 20 | 5 | - | 6 | 500 |
| HTSN-M3-5-3 | 2 | M3 | 5 | 6 | - | 6 | 500 |
| HTSN-M3-8-3 | 2 | M3 | 8 | 6 | - | 6 | 500 |
| HTSN-M3-10-3 | 2 | M3 | 10 | 6 | - | 6 | 500 |
| HTSN-M3-12-3 | 2 | M3 | 12 | 6 | - | 6 | 500 |
| HTSN-M3-15-3 | 2 | M3 | 15 | 6 | - | 6 | 500 |
| HTSN-M3-20-3 | 2 | M3 | 20 | 6 | - | 6 | 500 |
| HTSN-M4-5-3 | 2 | M4 | 5 | 6 | - | 6.4 | 500 |
| HTSN-M4-8-3 | 2 | M4 | 8 | 6 | - | 6.4 | 500 |
| HTSN-M4-10-3 | 2 | M4 | 10 | 6 | - | 6.4 | 500 |
| HTSN-M4-12-3 | 2 | M4 | 12 | 6 | - | 6.4 | 500 |
| HTSN-M4-15-3 | 2 | M4 | 15 | 6 | - | 6.4 | 500 |
| HTSN-M4-20-3 | 2 | M4 | 20 | 6 | - | 6.4 | 500 |
| HTSN-M4-25-3 | 2 | M4 | 25 | 6 | - | 6.4 | 500 |
| HTSN-M4-40-3 | 2 | M4 | 40 | 6 | - | 6.4 | 500 |
